HC43-2500 Guarding Alligator Shear

HC43-2500 Guarding Alligator Shear

Description:
The HC43-2500 alligator shear is used for a variety of cross sectional shape, such as: round, square steel, angle steel, I-beam, steel plate, steel and other scraps. This crocodile metal shear with 250 ton shear force is semi automatic. It’s easy to control. Notched blades of the alligator shear are particularly for cutting round stock.

Features of Guarding Alligator Shear:
1. The metal shear is compact in structure, with high mechanical properties and stability.
2. This alligator shear is driven hydraulically. What’s more, it’s easy to operate, safe and reliable.
3. The foot screws of crocodile metal shear are not compulsory in installation. The diesel engine can be put into use when the electricity is not available.
4. The length of shear scissors and the maximum shear force is adjustable according to user requirements.

Parameters:
Max Shear Force (TON): 250
Max Holding Force (TON): 26
Blade Length (MM): 1000
Max Blade Opening (MM): 480
Shear Frequency (time/min): 9-16
Material Size (MM): 70×70   Ø 80
Power (KW): 30
Operation: Manual feeding, manual or automatic operation

Up to now, our company has approved by ISO9001 (2000) Quality System, CQC and honored by “Jiangsu Famous-brand Product”. As a member of CRRA (China's Resources Recycling Assembly), MAC is also known as “Wuxi AAA Grade Trustworthy Enterprise”. MAC Industrial Co., Ltd has realized to produce 500 balers, 800 shears, 100 shredders and 25 set scrap steel shredder line annually.
